Bootstrapping topology and systemic risk of complex networks using the fitness model

Information about 10% of the links in a complex network is sufficient to reconstruct its main features and resilience with the fitness model.

Journal of Statistical Physics 151, 720 (2013)

N. Musmeci, S. Battiston, G. Caldarelli, M. Puliga, A. Gabrielli

Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model
Bootstrapping topology and systemic risk of complex networks using the fitness model

We present a novel method to reconstruct complex network from partial information. We assume to know the links only for a subset of the nodes and to know some non-topological quantity (fitness) characterising every node. The missing links are generated on the basis of the latter quantity according to a fitness model calibrated on the subset of nodes for which links are known. We measure the quality of the reconstruction of several topological properties, such as the network density and the degree distribution as a function of the size of the initial subset of nodes. Moreover, we also study the resilience of the network to distress propagation. We first test the method on ensembles of synthetic networks generated with the Exponential Random Graph model which allows to apply common tools from statistical mechanics. We then test it on the empirical case of the World Trade Web. In both cases, we find that a subset of 10 % of nodes is enough to reconstruct the main features of the network along with its resilience with an error of 5%.
